Technical sheet

Brand

Brand: OnePlus
Aliases: CPH2709
Best Sellers: OnePlus 15 From € 704 OnePlus 15R From € 556 OnePlus Nord CE5 From € 279 OnePlus Nord 6 From € 405 OnePlus Nord 5 From € 313

Release Date

Release date: July 2025, 1 year ago

Design & Materials

Image gallery

Image gallery

Structure

Size: 77.0 mm • 163.4 mm • 8.1 mm
Weight: 211 g
Usable surface: 92 %
Materials: Glass , Aluminium
Resistance certificates (dust, water): IP65
Colors: White Gray Beige Ice
Repairability: Class A B C D E
Drop resistance: Class A B C D E • 90 drops without defects

Screen

Diagonal: 6.83"
Type: AMOLED
Aspect Ratio: 20:9
Resolution: 1272 x 2800 px • QHD
Density: 456 ppi • Very high density
Others: Hole-punch Notch 2160 Hz PWM Refresh rate 120 Hz Refresh rate 144 Hz Brightnes 500 cd/m² (typ) Peak brightness - 1800 cd/m² Max brightness HBM - 1100 cd/m² Max brightness HBM - 1400 cd/m² Peak brightness - 2200 cd/m² Always-On Display HDR10+ DCI-P3 10 Bits panel Scratch resistant 3D curved glass screen Corning Gorilla Glass 7i Capacitive Multi-touch Frameless

Performance & Hardware

Processor

Model: Qualcomm Snapdragon 8s Gen3
CPU: 1x3 Ghz Cortex•X4, 4x2,8 Ghz Cortex•A720, 3x2,0 Ghz Cortex•A520
Type: Octa-Core
Nanometer: 4 nm
Frequency: 3 GHz
64 Bits: Yes

Graphics

GPU: Adreno 735

RAM

RAM: 8 GB

Camera

Double rear camera

Standard: 1
Resolution: 50 Mpx
Aperture: ƒ/ 1.8
Sensor: Sony LYT-700C
Type: CMOS
Sensor size: 1/1.56"
Pixel size: 0.80 µm
Pixel Binning: 1-4 (2x2)
Flash: Quad LED

Connectivity

Bands

5G: n1 (2100), n2 (1900 PCS), n3 (1800), n5 (850), n7 (2600), n8 (900), n12 (700), n20 (800), n28b (700), n28a (700), n38 (2600), n40 (2300), n41 (2500), n66 (1700), n75 (1500), n77 (3700), n78 (3500)
4G LTE: B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B17 (700), B18 (800), B19 (800), B20 (800), B26 (850), B28b (700), B28a (700), B32 (1500), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B42 (TDD 3500), B66 (1700/2100)
3G: B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B6 (800), B8 (900), B19 (800)
2G: B2 (1900), B3 (1800), B5 (850), B8 (900)

SIM card

Type: Dual SIM Dual Standby (Nano SIM + Nano SIM) SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM...

Wi-Fi

Standards

Battery

Capacity: 5200 mAh
Type: Li-Polymer
Fast charge: Yes , 80.0W
Others: Bypass Charging Reverse charging Non-removable
Efficiency: B G A
Runtime per charge: ~ 49h
Charge cycles: 1200 cycles

Software

Operating System: Android 16 OxygenOS 16 (Android 16)
Google Services: With Google Mobile Services
Widevine L1: Yes
Updates: OS updates: 4 years Security updates: 6 years
