Technical sheet

Brand

Brand: OnePlus
Aliases: DN2103
Best Sellers: OnePlus 15 From € 764 OnePlus 15R From € 556 OnePlus Nord CE5 From € 279 OnePlus Nord 6 From € 405 OnePlus Nord 5 From € 313

Release Date

Release date: July 2021, 5 years ago

Design & Materials

Image gallery

Image gallery

Structure

Size: 73.3 mm • 159.1 mm • 8.2 mm
Weight: 189 g
Usable surface: 88 %
Materials: Plastic , Glass
Colors: Gray Cyan

Screen

Diagonal: 6.43"
Type: Super AMOLED Samsung E3
Aspect Ratio: 20:9
Resolution: 1080 x 2400 px • FHD+
Density: 402 ppi • Very high density
Others: Hole-punch Notch Refresh rate 90 Hz Touch sampling rate 180 Hz Brightnes 500 cd/m² (typ) HDR10+ DCI-P3 Full sRGB standard Scratch resistant 2.5D curved glass screen Corning Gorilla Glass 5 Capacitive Multi-touch Frameless

Performance & Hardware

Processor

Model: MediaTek Dimensity 1200 (MT6893)
CPU: 1x Cortex•A78 3.0 GHz + 3x Cortex•A78 2.6 GHz + 4x Cortex•A55 2.0 GHz
Type: Octa-Core
Nanometer: 6 nm
Frequency: 3 GHz
64 Bits: Yes

Graphics

GPU: 9x Arm Mali-G77 MC9 886MHz

RAM

RAM: 8 GB

Camera

Triple rear camera

Standard: 1
Resolution: 50 Mpx
Aperture: ƒ/ 1.8
Sensor: Sony IMX766
Type: CMOS
Sensor size: 1/1.56"
Pixel size: 1.00 µm
Pixel Binning: 1-4 (2x2)
Flash: Dual LED

Connectivity

Bands

5G: n1 (2100), n3 (1800), n7 (2600), n8 (900), n20 (800), n28b (700), n28a (700), n38 (2600), n41 (2500), n78 (3500)
4G LTE: B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B17 (700), B18 (800), B19 (800), B20 (800), B26 (850), B28b (700), B28a (700), B32 (1500), B34 (TDD 2100), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B66 (1700/2100)
3G: B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B6 (800), B8 (900), B19 (800)
2G: B2 (1900), B3 (1800), B5 (850), B8 (900)

SIM card

Type: Dual SIM Dual Standby (Nano SIM + Nano SIM) SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM...

Wi-Fi

Standards: 802.11a , 802.11b , 802.11g , 802.11n , 802.11n 5GHz , 802.11ac, WiFi 6 (802.11ax)

Battery

Capacity: 4500 mAh
Type: Li-Polymer
Fast charge: Yes , 65.0W
Others: Non-removable

Software

Operating System: Android 12 Snow Cone OxygenOS 12 (Android 12)
Google Services: With Google Mobile Services
