Technical sheet

Brand

Brand: Nubia
Best Sellers: nubia Z80 Ultra From € 647 Nubia Focus 2 5G From € 165 nubia Z70 Ultra From € 494 Nubia Flip 2 From € 288 Nubia Air From € 182

Release Date

Release date: July 2020, 6 years ago

Design & Materials

Image gallery

Image gallery

Structure

Size: 78.0 mm • 168.6 mm • 9.8 mm
Weight: 218 g
Usable surface: 82 %
Materials: Aluminium alloy , Glass
Colors: Ice

Screen

Diagonal: 6.65"
Type: AMOLED
Aspect Ratio: 19.5:9
Resolution: 1080 x 2340 px • FHD+
Density: 388 ppi • High Density
Others: Without Notch Refresh rate 144 Hz Touch sampling rate 240 Hz Peak brightness - 1000 cd/m² Max brightness HBM - 600 cd/m² 100000:1 contrast ratio TÜV Rheinland Eye Comfort Certification HDR10+ DCI-P3 DC dimming LED Notifications Scratch resistant Corning Gorilla Glass Capacitive Multi-touch Physical buttons

Performance & Hardware

Processor

Model: Qualcomm Snapdragon 865
CPU: 1x Cortex•A77 2.84 GHz + 3x Cortex•A77 2.4 GHz + 4x Cortex•A55 1.8 GHz
Type: Octa-Core
Nanometer: 7 nm
Frequency: 2.84 GHz
64 Bits: Yes

Graphics

GPU: Qualcomm Adreno 650 600 Mhz

RAM

RAM: 8 GB

Camera

Triple rear camera

Standard: 1
Resolution: 64 Mpx
Aperture: ƒ/ 1.8
Sensor: Sony IMX686 Exmor RS
Type: CMOS
Sensor size: 1/1.7"
Pixel size: 0.80 µm
Pixel Binning: 1-4 (2x2)
Flash: LED

Connectivity

Bands

5G: n41 (2500), n78 (3500)
4G LTE: B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B17 (700), B18 (800), B19 (800), B20 (800), B26 (850), B34 (TDD 2100), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500)
3G: B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B8 (900), B19 (800)
2G: CDMA BC0 (800), CDMA BC1 (1900), B2 (1900), B3 (1800), B5 (850), B8 (900)

SIM card

Type: Dual SIM Dual Standby (Nano SIM + Nano SIM) SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM...

Wi-Fi

Standards: 802.11a , 802.11b , 802.11g , 802.11n , 802.11n 5GHz , 802.11ac, WiFi 6 (802.11ax)

Battery

Capacity: 4500 mAh
Type: Li-Polymer
Fast charge: Yes , 55.0W
Others: Non-removable
Extra: 55W PD Quick Charger is sold separately

Software

Operating System: Android 10 Q Android 10
Google Services: With Google Mobile Services
