Motorola Edge 40 Neo · Unboxing TN

Technical sheet

Brand

Brand: Motorola
Aliases: XT2307-1
Best Sellers: Motorola Edge 70 Pro From € 472 motorola Edge 70 fusion From € 284 Motorola Edge 60 Neo From € 390 Motorola Edge 60 Pro From € 449 Motorola Moto G86 Power

Release Date

Release date: September 2023, 3 years ago

Design & Materials

Image gallery

Image gallery

Structure

Size: 72.0 mm • 159.6 mm • 7.8 mm
Weight: 170 g
Usable surface: 90 %
Materials: Plastic , Faux leather
Resistance certificates (dust, water): IP68
Colors: Black Blue Green Orange

Screen

Diagonal: 6.55"
Type: pOLED
Aspect Ratio: 21:9
Resolution: 1080 x 2400 px • FHD+
Density: 395 ppi • High Density
Others: Hole-punch Notch SGS Certified Refresh rate 144 Hz Touch sampling rate 360 Hz Peak brightness - 1300 cd/m² HDR10+ DCI-P3 Scratch resistant Corning Gorilla Glass 3 2.5D curved glass screen Capacitive Multi-touch Frameless

Performance & Hardware

Processor

Model: MediaTek Dimensity 7030
CPU: 2x2.25 GHz ARM Cortex•A78+6x 2.0 GHz ARM Cortex•A55
Type: Octa-Core
Nanometer: 6 nm
Frequency: 2.25 GHz
64 Bits: Yes

Graphics

GPU: Mali-G610 MC3

RAM

RAM: 12 GB

Camera

Double rear camera

Standard: 1
Resolution: 50 Mpx
Aperture: ƒ/ 1.8
Sensor: Omnivision OV50A
Type: CMOS
Sensor size: 1/1.55"
Pixel size: 1.00 µm
Pixel Binning: 1-4 (2x2)
Flash: Dual LED

Connectivity

Bands

5G: n1 (2100), n2 (1900 PCS), n3 (1800), n5 (850), n7 (2600), n8 (900), n20 (800), n28b (700), n28a (700), n38 (2600), n40 (2300), n41 (2500), n66 (1700), n77 (3700), n78 (3500)
4G LTE: B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B13 (700), B17 (700), B18 (800), B19 (800), B20 (800), B25 (1900+), B26 (850), B28b (700), B28a (700), B32 (1500), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B42 (TDD 3500), B43 (TDD 3700), B48 (TDD 3600), B66 (1700/2100)
3G: B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B8 (900), B19 (800)
2G: B2 (1900), B3 (1800), B5 (850), B8 (900)

SIM card

Type: Dual SIM Dual Standby (Nano SIM + eSIM) SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM...

Wi-Fi

Battery

Capacity: 5000 mAh
Type: Li-Polymer
Fast charge: Yes , 68.0W
Others: Reverse charging Non-removable

Software

Operating System: Android 15 Android 15
Google Services: With Google Mobile Services
Updates: OS updates: 3 years Security updates: 3 years
