Technical sheet

Brand

Brand: Asus
Aliases: ZS673KS
Best Sellers: Asus ZenFone Pegasus 4A Asus Rog Phone 9 FE Asus ZenFone Max (2016) Asus ZenFone Max Asus ZenFone 4 Max ZC520KL

Release Date

Release date: July 2022, 4 years ago

Design & Materials

Image gallery

Image gallery

Structure

Size: 77.0 mm • 173.0 mm • 10.4 mm
Weight: 239 g
Usable surface: 82 %
Materials: Glass
Resistance certificates (dust, water): IPX4
Colors: Black White

Screen

Diagonal: 6.78"
Type: AMOLED Samsung E4
Aspect Ratio: 20:9
Resolution: 1080 x 2340 px • FHD+
Density: 380 ppi • High Density
Others: Without Notch Eye Care Display Refresh rate 165 Hz Touch sampling rate 720 Hz Max brightness HBM - 800 cd/m² Peak brightness - 1200 cd/m² Always-On Display TÜV Rheinland Eye Comfort Certification HDR10+ DCI-P3 DC dimming sRGB standard NTSC Color LED Notifications Scratch resistant Corning Gorilla Glass Victus Capacitive Multi-touch Physical buttons 1 ms response time Oleophobic coating

Performance & Hardware

Processor

Model: Qualcomm Snapdragon 8+ Gen1
CPU: 1x3.2 GHz Cortex•X2 +3x2.8 GHz Cortex•A710 + 4x2.0 GHz Cortex•A510
Type: Octa-Core
Nanometer: 4 nm
Frequency: 3.2 GHz
64 Bits: Yes

Graphics

GPU: Qualcomm Adreno 730 875 MHz

RAM

RAM: 12 GB

Camera

Triple rear camera

Standard: 1
Resolution: 50 Mpx
Aperture: ƒ/ 1.9
Sensor: Sony IMX766
Type: CMOS
Sensor size: 1/1.56"
Pixel size: 1.00 µm
Pixel Binning: 1-4 (2x2)
Flash: LED

Connectivity

Bands

5G: n1 (2100), n3 (1800), n7 (2600), n8 (900), n20 (800), n28b (700), n28a (700), n38 (2600), n40 (2300), n41 (2500), n77 (3700), n78 (3500), n79 (4700)
4G LTE: B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B18 (800), B19 (800), B20 (800), B26 (850), B28b (700), B28a (700), B32 (1500), B34 (TDD 2100), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B42 (TDD 3500), B48 (TDD 3600)
3G: B1 (2100), B2 (1900), B4 (1700/2100 AWS A-F), B5 (850), B8 (900)
2G: B2 (1900), B3 (1800), B5 (850), B8 (900)

SIM card

Type: Dual SIM Dual Standby (Nano SIM + Nano SIM) SIM cards (MiniSIM) can be cut to MicroSIM, MicroSIM can be cut to NanoSIM and a SIM can even be cut to a NanoSIM (although not recommended). Download this SIM Cutting Template and forget about having to ask your operator for a new SIM...

Wi-Fi

Standards: 802.11a , 802.11b , 802.11g , 802.11n , 802.11n 5GHz , 802.11ac, 802.11ad , WiFi 6 (802.11ax)

Battery

Capacity: 6000 mAh
Type: Li-Polymer
Fast charge: Yes , 65.0W
Others: Bypass Charging Reverse charging Non-removable
Extra: Reverse charging 10W

Software

Operating System: Android 14 Upside-down cake Android 14
Google Services: With Google Mobile Services
